| Place of Origin: | China |
| Brand Name: | EFFEMAX |
| Certification: | No |
| Model Number: | HSS |
| Minimum Order Quantity: | 10pcs |
|---|---|
| Price: | 50USD/PC |
| Packaging Details: | carton |
| Delivery Time: | 25 DAYS |
| Payment Terms: | T/T |
| Supply Ability: | 1000PCS/M |
| Material: | M2,Dmo5 | Diameter: | 285-450mm |
|---|---|---|---|
| Coating: | Tin |
Cold cut TiN Titanium Nitride coat 450x3.0mm M2 HSS circular saw blade
TIN coating: Titanium Nitride Coating, it’s an excellent PVD coating for protecting saw blade from wear, it improve the cutting life of saw blade. Furthermore, it is a good choice for iron based materials and cutting condition’s requiring resistance to both abrasive and adhesive wear. TiN coated allows cutting of materials with high tensile strengths.
Mainly used in bicycles, stroller industry, pipe manufacturers and building decoration industry
Coating thickness of 2-4 microns,
Surface hardness: 2200HV,
Friction coefficient of 0.55,
Cutting temperature below 520 degrees
Advantages:
Cost effective due to a sophisticated PVD coating for wear protection
Low friction coefficient
Cuts much faster and has a much longer blade life than the steam treated blade
Good wear protection due to the smooth coating surface
Higher cutting speed rates
Ideal for cutting stainless steel and sticky, gummy materials
Application industry:
Automobile, motorcycle, steel furniture, gym faciliti, bicycles, stroller, baby carriage industry and building decoration industry, thick-walled metal pipe factory,sanitary ware and other industries, cutting ordinary steel pipe, stainless steel pipe, copper, aluminum and other materials
HSS material:
M35, M42, DMo5, DMo6, W6Mo5Cr4V2 (M2), W18Cr4V (W18), W9Mo3Cr4V (W9)
Surface coating: polished, steam-treated, TIN, TiCN, TiALN, CrN, ALTIN
Size: 200mm-450mm
Thickness: 1.2-3.5mm
Bore Diameter: 32mm, 40mm, 50mm, or as request.
Tooth Type: A/ AW/ B/ BW
| Diameter mm | Bore mm | Thickness mm | Teeth profile | Surface coating |
| 160 | 32 | 1.2/1.5/2.0 |
Aw A B Bw C/HZ |
VAPO TIN CrN TIALN TICN |
| 200 | 32 | 1.2/1.5/1.8/2.0/2.5 | ||
| 220 | 32 | 1.2/1.5/1.8/2.0/2.5 | ||
| 250 | 32 | 1.2/1.5/2.0/2.5/3.0 | ||
| 250 | 40 | 2.0/2.5/3.0 | ||
| 275 | 32 | 1.6/2.0/2.5/3.0 | ||
| 275 | 40 | 1.6/2.0/2.5/3.0 | ||
| 300 | 32 | 1.6/2.0/2.5/3.0 | ||
| 300 | 40 | 1.6/2.0/2.5/3.0 | ||
| 315 | 32 | 1.6/2.0/2.5/3.0/3.5 | ||
| 315 | 40 | 1.6/2.0/2.5/3.0/3.5 | ||
| 325 | 32 | 2.0/2.5/3.0 | ||
| 325 | 40 | 2.0/2.5/3.0 | ||
| 350 | 32 | 2.0/2.5/3.0/3.5 | ||
| 350 | 40 | 2.0/2.5/3.0/3.5 | ||
| 350 | 50 | 2.0/2.5/3.0/3.5 | ||
| 400 | 40 | 2.5/3.0/3.5 | ||
| 400 | 50 | 2.5/3.0/3.5 | ||
| 425 | 40 | 2.5/3.0/3.5 | ||
| 425 | 50 | 2.5/3.0/3.5 | ||
| 450 | 40 | 2.5/3.0/3.5 | ||
| 450 | 50 | 2.5/3.0/3.5 |
