75Cr1 material tempering steel circular steel cores for trenching machine

75Cr1 material tempering steel circular steel cores for trenching machine

    • 75Cr1 material tempering steel circular steel cores for trenching machine
    • 75Cr1 material tempering steel circular steel cores for trenching machine
    • 75Cr1 material tempering steel circular steel cores for trenching machine
    • 75Cr1 material tempering steel circular steel cores for trenching machine
    • 75Cr1 material tempering steel circular steel cores for trenching machine
    • 75Cr1 material tempering steel circular steel cores for trenching machine
  • 75Cr1 material tempering steel circular steel cores for trenching machine

    Product Details:

    Place of Origin: China
    Brand Name: EF
    Certification: No
    Model Number: diamond saw blank

    Payment & Shipping Terms:

    Minimum Order Quantity: 5PCS
    Price: 600-1000USD
    Packaging Details: wooden case
    Delivery Time: 45 days
    Payment Terms: T/T
    Supply Ability: 1000PCS/Month
    Contact Now
    Detailed Product Description
    Material: 75Cr1 Diameter: 1982mm
    Brazing: High Frequency

    75Cr1 material tempering steel circular steel cores for trenching machine





    Diamond saw blanks and steel cores for block cutting of slabs of Granite, Sandstone, Marble, and Kinds of Hard Stones after brazing diamond segments, Suitable for Bridge cutting machine, Single arm cutting machine, Vertical plus horizontal cutting machine, and Block squaring cutter, Gantry cutting machine, Bridge multiblade block cutter.



    The diameter range from 530mm-3500mm

    Type: Normal and silent type, wet and dry cutting are both available.

    The segments can be welded on the saw base body, high frequency induction welding, laser welding or silver welding.



    Diamond saw blanks and steel cores are made with high strength special steel, precisely heat treated, grinded, straightened and tensioned and uniform metallurgical structure.



    Circular Saw Blanks for single & multi cutters for granite & stone cutting with water.



    Our saw blanks are made of high quality steel with chemical composition 75Cr1, which is considered as the best quality for granite & stone cutting offering long lifespan.



    Type: wet and dry cutting are both available.



    The segments can be welded on the saw base body, high frequency induction welding, laser welding or silver welding.



    75Cr1 material tempering steel circular steel cores for trenching machine

    Specification



    Diameter D1 Thickness Teeth number Slot depth Slot width Teeth height
    800 790 4.5 46 14 12 41.9
    830 815 4.5 46 14 12 43.6
    850 840 4.5 50 18 12 40.8
    900 884 5.0 64 18 18 25.4
    1000 984 5.0 70 20 20 24.1
    1050 1034 5.0 70 20 20 26.4
    1100 1084 5.5 74 20 20 26.0
    1200 1184 5.5 80 20 20 26.5
    1250 1232 6.0 84 20 20 26.1
    1300 1282 6.0 88 20 20 25.8
    1350 1332 6.0 88 22 22 25.5
    1400 1382 6.5 92 22 22 25.2
    1500 1482 6.5 100 22 22 24.5
    1500 1482 7.0 100 22 22 24.5
    1600 1582 6.5 104 22 22 25.8
    1600 1582 7.0 104 22 22 25.8
    1650 1632 7.0 108 22 22 25.5
    1700 1682 7.0 112 22 22 25.2
    1750 1732 7.0 112 22 22 26.6
    2000 1982 8.0 132 22 22 25.2
    2100 2082 8.0 132 25 22 27.5
    2200 2182 8.0 132 25 22 29.9
    2300 2282 8.0 138 25 22 29.9
    2500 2482 9.0 140 25 25 30.7
    2700 2682 9.0 140 25 25 35.2
    3000 2982 9.25 160 30 30 28.5
    3500 3482 9.5 180 30 30 30.8
    3600 3582 9.5 180 30 30 31.0
