Steel profile cold cut 8CrV circular tungsten carbide tipped saw blade

Steel profile cold cut 8CrV circular tungsten carbide tipped saw blade

Tungsten Carbide-Tipped (TCT) cold saw blades are made with an alloy steel body and tungsten carbide inserts brazed to the tips of the teeth. These tips are ground on all surfaces to create tangential and radial clearance and provide the proper cutting and clearance angles on the teeth. The alloy body is generally made from a wear resistant material such as a chrome vanadium steel, heat treated to 38/42 HRc . The tungsten carbide tips are capable of operating at much higher temperatures than solid HSS cold saw blades, therefore, TCT cold saw blades are usually run at much higher surface speeds. This allows carbide-tipped blades to cut at faster rates and still maintain an acceptable chip load per tooth. The tungsten carbide inserts are extremely hard (98 HRc) and capable of very long wear life. However, they are less resistant to shock than solid HSS cold saw blades. Any vibration during the cutting process may severely damage the teeth.

Carbide Tipped

Tubes and solids

Stainless steel, alloy steel and special purpose steel

Carbon content greater than .45%

Coated Carbide Tipped

Tubes and solids

High carbon steel alloys

Reduces heat-wear and distortion

Advantages:

Lower cost per cut

Wide variety of tooth counts to accommodate your part

Stiff and extremely flat plates ensure distortion-free accurate cuts

Increased productivity (less downtime)

Excellent cut quality

Cutting materials suggested:

Mild low carbon steel

Stainless steel

High carbon steel

Solids and pipe

Carbide-Tipped Circular Saw Blade (TCT) for section steel

It is mainly used for cutting H beam, Channel, Angle, square hollow. It also can be used for cutting the steel rails of normal temperature and used with various kinds of cutting machines in and abroad.

Cutting materia size
