    Product Details:

    Place of Origin: China
    Brand Name: EF
    Model Number: 273

    Payment & Shipping Terms:

    Minimum Order Quantity: 1
    Price: 175000
    Packaging Details: seaworthy package
    Delivery Time: 3 months
    Payment Terms: T/T
    Supply Ability: 1 set in three month
    Contact Now
    Detailed Product Description
    Cutting Type: Double Blade Model: 219
    Max Cutting Thickness: 10mm Max Dia: 219mm
    Cutting Material: Steel Pipe And Tube

    Fully automatic double blade CNC profiling milling saw for 273 diameter tube





    Cutting method

    There are 2 milling saw blades to cut along the outer contour of the pipe.



    The CNC milling fixed-length flying saw machine is composed of two parts: mechanical structure and automatic control system. The user sets the cutting length, pipe parameters and other information on the operating table, and the CNC milling fixed-length flying saw machine automatically completes the full cycle process of quick start, synchronous tracking, clamping cutting and quick return.



    Advantages of profile milling saw

    Save saw blades and reduce costs:

    The saw blades on both sides extend the pipe wall into the cut to realize the imitating pipe wall cutting that simulates the pipe trajectory. Thus, the size of the saw blades used is greatly reduced, and the price of two small-size saw blades is lower than that of large saw blades with conventional cutting methods.

    Carbide tipped saw blade, increase strength:

    It can cut welded pipes with internal ribs and high-strength materials. It has a wider application range and greatly improves the life of the saw blade. The cutting life is more than twice that of ordinary saw blades.

    Online cut-to-length, stable quality and high efficiency:

    According to the cutting pipe type, pipe diameter, wall thickness, production line speed requirements and other working conditions, the cutting solution can be tailored for users through the servo system. Thereby improving equipment efficiency and stability, saving material and time costs.





    Milling saw 219
    Cutting material Q195 Q235 SPCC



    Cutting range

    Round tube Max 219mm Thickness:2.0-10mm
    Square tube Max150x150mm
    Rectangular tube
    Production speed range 36-40m/min(when CTL 6 meters, OD140mm,thickness 3.0mm)
    Cut to length Min 1500mm
    Length tolerance +-1.5mm, the speed fluctuation of the production line is required to not exceed 2%
    Burr height after cutting Max 0.25mm
    Voltage AC 380V,3PH,50HZ
    Mechanical part
    Milling saw length 8600*1800*1800mm(The final drawings shall prevail.)
    Motor Drive motor: 22KW Servo Motor
    Turntable motor: 3.14KW
    Turntable motor: 3.14KW
    Feed motor:1.9KW
    Feed motor:1.9KW
    Saw blade motor: 15KW
    Saw blade motor: 15KW
    Lifting motor:3.3KW
    Linear guide rail Taiwan HIWIN 65
    Clamping device Hydraulic type
    The specifications and models of the clamp block are provided the inlet end is tapered to prevent the steel pipe from being scratched
    Oil supply system Automatic fueling device
    Saw blade TCT
    Spindle gearbox Taiwan Liming
    Gear rack Taiwan KH
    Cable protection Domestic drag chain
    Trolley protection with trolley safety buffers at the front and rear of the sawing machine
