HSS saw blade teeth tip grinding CNC control automatic sharpening machine

HSS saw blade teeth tip grinding CNC control automatic sharpening machine

    • HSS saw blade teeth tip grinding CNC control automatic sharpening machine
    • HSS saw blade teeth tip grinding CNC control automatic sharpening machine
    • HSS saw blade teeth tip grinding CNC control automatic sharpening machine
    • HSS saw blade teeth tip grinding CNC control automatic sharpening machine
    • HSS saw blade teeth tip grinding CNC control automatic sharpening machine
    • HSS saw blade teeth tip grinding CNC control automatic sharpening machine
  • HSS saw blade teeth tip grinding CNC control automatic sharpening machine

    Product Details:

    Place of Origin: China
    Brand Name: EF
    Certification: No
    Model Number: CNC

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set
    Price: USD22000/set
    Packaging Details: wooden case
    Delivery Time: 25 days
    Payment Terms: T/T
    Supply Ability: 50 sets per month
    Contact Now
    Detailed Product Description
    Control: CNC Control Usage: Hss Saw Blade Teeth Grinding
    Teeth Type: A, AW,B,BW Total Power: 6kW
    Total Weight: 1.5t

    HSS saw blade teeth tip grinding CNC control automatic sharpening machine



    CNC automatic grinding machine is the most advanced grinding machine in China. Through the cooperation of mechanical, electrical, hydraulic, PLC and HMI interface, CNC automatic grinding machine can ensure high grinding quality and make saw blade more cutting-resistant. The normal speed of grinding process is 8 minutes, one time setting tooth shape, full automatic grinding, which can be divided into the following steps: knife-input saw blade outer diameter teeth number-automatic calculation-cycle start, fool-type operation of a circle forming, machine equipped with a magnetic sludge separator, powder automatic processing, clean, environmentally friendly and pollution-free, a grinding wheel. The blade can grind any tooth profile. The perfect tooth profile improves the saw blade's cutting ability by more than two times in the cutting life. It has many advantages such as safety, efficiency, convenience, stability, energy saving and material saving. It is well received by buyers at home and abroad.



    Main Overview:



    A variety of cutting-edge tooth shape, can be completed by one grinding



    Do not need a long grinding time, reduce non-productive time, achieve high quality grinding effect.



    CNC Four-axis control bevel grinding, grinding wheel feed, grinding stroke and teeth feeding.



    Several kinds of complex sawtooth geometries, and provide different grinding bevel angles and the height of the teeth.



    Achieve outstanding results by use of water-based coolant or oil.



    Input data directly in the center of the control panel.



    The operator uses the program by guide illustration through LCD color screen support.



    No longer required to set tooth pitch in advance, but simply enter the diameter and number of teeth.



    Innovative and unique design, machine complete seal



    Separation area of grinding zone and computer



    Parameters



    No Item   Data Remark
    1 Using range Grinding diameter ≤100-500
        Saw blade thickness ≤0-1-6.0
        Saw blade hole diameter Φ22-25.4-32-40-50
        Teeth type A, B,BW,C
        Angle range 0-80°
        Tooth pitch Max 24MM
        Teeth qty 10-99 9teeth
        Speed 1-20 teeth/min
    2 Data Grinding wheel drive motor 4.0KW
        Grinding wheel CBN
        Grinding wheel line speed 6000
        Feeding servo motor 0.75KW
    3   Left and right stepping motor 0.2KW
        Guide rail oil pump capacity 300L
        Total power 6KW





    HSS saw blade teeth tip grinding CNC control automatic sharpening machine

    HSS saw blade teeth tip grinding CNC control automatic sharpening machine

    HSS saw blade teeth tip grinding CNC control automatic sharpening machine

    HSS saw blade teeth tip grinding CNC control automatic sharpening machine

    HSS saw blade teeth tip grinding CNC control automatic sharpening machine
