High frequency welding U slot stone cutting diamond saw blank and steel core

High frequency welding U slot stone cutting diamond saw blank and steel core

    • High frequency welding U slot stone cutting diamond saw blank and steel core
    • High frequency welding U slot stone cutting diamond saw blank and steel core
    • High frequency welding U slot stone cutting diamond saw blank and steel core
    • High frequency welding U slot stone cutting diamond saw blank and steel core
  • High frequency welding U slot stone cutting diamond saw blank and steel core

    Product Details:

    Place of Origin: China
    Brand Name: Effemax
    Certification: No
    Model Number: 2182mm

    Payment & Shipping Terms:

    Minimum Order Quantity: 5 pcs
    Price: USD600-1000 per PC
    Packaging Details: wooden case or steel shelf
    Delivery Time: 40 days
    Payment Terms: T/T
    Supply Ability: 1000PCS/month
    Contact Now
    Detailed Product Description
    Saw Blank Material: 75Cr1 Size: 2182mm*8mm
    Machine: Bridge Multiblade Block Cutter

    High frequency welding U slot stone cutting diamond saw blank and steel core



    Adopt special crafts for multi work to make the cores working in one set with the same parameter in diameter, bore hole, thickness, hardness, flatness, axial run out and tension.



    Advantages: Cutting synchronously with multi blades makes a better working efficiency. thin steel cores with thickness 3.0-6.5mm could reduce material waste and inprove finished product rate, high cutting speed, low noise and energy saving.



    Application machine: Bridge multiblade block cutter.



    The diameter range from 684-2982mm



    Raw material: Our saw blanks are made of high quality steel with chemical composition 75Cr1, which is considered as the best quality for granite & stone cutting offering long lifespan.



    Diamond saw blanks and steel cores for block cutting of slabs of Granite, Sandstone, Marble, and Kinds of Hard Stones after brazing diamond segments, Suitable for Bridge cutting machine, Single arm cutting machine, Vertical plus horizontal cutting machine, and Block squaring cutter, Gantry cutting machine, Bridge multiblade block cutter.



    The diameter range from 530mm-3500mm

    Type: Normal and silent type, wet and dry cutting are both available.

    The segments can be welded on the saw base body, high frequency induction welding, laser welding or silver welding.



    Diamond saw blanks and steel cores are made with high strength special steel, precisely heat treated, grinded, straightened and tensioned and uniform metallurgical structure.



    Circular Saw Blanks for single & multi cutters for granite & stone cutting with water.



    Our saw blanks are made of high quality steel with chemical composition 75Cr1, which is considered as the best quality for granite & stone cutting offering long lifespan.



    Thin saw blank for environmental protection, hollow saw blank for energy-saving, processing by quenching, the thickness is thinner than their counterparts about 1-1.5mm, reduce the weight of 10%, reduce power loss of 30%, and increase in yield of 5%, hollow saw blank processing release stress, prevent deformation, prolong the service life of the saw blade.



    High frequency welding U slot stone cutting diamond saw blank and steel core



    High frequency welding U slot stone cutting diamond saw blank and steel core





    Diameter Steel core diameter Thickness Teeth number Slot depth Slot width Teeth height
    700 684 5.0 60 18 10 25.8
    800 784 5.5 66 18 12 25.3
    840 822 5.5 66 18 14 25.1
    860 842 5.5 66 18 14 26.1
    900 884 5.0 64 18 18 25.4
    1000 984 5.0 70 20 20 24.2
    1000 984 5.5 70 20 20 24.2
    1100 1084 5.5 74 20 20 26.0
    1200 1184 5.5 80 20 20 26.5
    1300 1282 5.5 88 20 20 25.7
    1400 1382 5.5 92 22 22 25.2
    1600 1582 5.5 104 22 22 25.8
    1700 1682 5.5 112 22 22 25.2
    2200 2182 8.0 132 22 22 29.9
    3000 2982 9.0 160 30 30 28.6
